An isolation joint separates the concrete slab on grade from the structural steel column base plate and footing block-out. A one-half-inch-thick full slab depth isolation joint filler strip lines the temporary edge of the slab block-out, with a round configuration allowed at the contractor's option. The slab rests upon a vapor barrier, a leveling course of fine-grained aggregate, and a one-foot-thick base course of sandy gravel, crushed rock, or approved open-graded material compacted to ninety-five percent relative compaction over undisturbed soil. The surrounding slab features a thickened edge and control joints radiating outward from the column block-out corners at a typical three-inch clearance.
VAPOR BARRIER SLAB ON GRADE REF. PLAN PLAN REF. LEVELING COURSE OF FINE GRAINED AGGREGATE SANDY GRAVEL OR CRUSHED ROCK, OR OTHER APPROVED OPEN-GRADED BASE COURSE. INCREASE THICKNESS OF BASE COURSE AS REQUIRED BY GEOTECHNICAL ENGINEER. COMPACT TO 95% RELATIVE COMPACTION REF. GEOTECH UNDISTURBED SOIL 1' - 0" TYP. 3" CLR. BASE PL TEMPORARY EDGE OF SLAB BLOCK-OUT w/ 1/2" THICK FULL SLAB DEPTH ISOLATION JOINT FILLER STRIP. ROUND CONFIGURATION MAY BE USED AT CONTRACTOR'S OPTION. REF. SPECIFICATIONS FOR ADDITIONAL INFORMATION COLUMN REF. PLAN WF OR HSS SLAB ON GRADE CONTROL JOINT SLAB EDGE THICKENED
