Longitudinal conduits are restricted within eight inches of the steel beam centerline, and perpendicular conduits are prohibited in the middle one-third of the beam span. The structural engineer of record must be notified if these conditions cannot be met.
8" 8" NO LONGITUDINAL CONDUIT W/IN 8" OF BM STL BM CONDUIT PERP TO STL BMS IS NOT PERMITTED IN MIDDLE 1/3 OF BM SPAN NOTES: 1. EOR IS TO BE NOTIFIED IF CONDITIONS OF THIS DETAIL CONNOT BE MET.
