This structural connection detail shows gusset plates welded to flange plates with a one-half inch fillet weld. The assembly incorporates E80 electrodes on each flange plate with specific equal spacing dimensions of three inches and eight and one-half inches. Bolt patterns are arranged symmetrically across the connection plates.
3" EQ SPCG 8 1/2" EQ SPCG 3" 1/2 FLG PL GUSSET PLS SECTION B E80, EA FLG PL ((1 3/4))
