An HSS4x4x5/16 post aligns and spaces at typical mullions with metal studs infilling between the posts. A seismic gap separates the atrium framing from the adjacent structure. An HSS4x4x5/16 parapet is supported by an HSS4x4x5/16 frame spaced at 6'-0" on center. Complete joint penetration welds are specified on three sides at connection points.
HSS4x4x5/16 POST ALIGN AND SPACE AT MULLIONS TYP INFILL W/ MTL STUDS BTWN POST HSS4x4x5/16 PARAPET HSS4x4x5/16 FRAME @ 6'-0"OC CJP (3) SIDES CJP SEISMIC GAP, SAD
