A supported steel beam framing into a wide-flange column flange via a shear angle sized per plan. Four bolts secure the beam web to the vertical leg of the shear angle, positioned at a four-inch clearance from the column face. The wide-flange column is sized per plan with a top-of-steel elevation noted where applicable.
4" ® SUPPORTED BEAM & ANGLE SHEAR ANGLE PER 2/S5.01 ® BOLTS ® COL. WF COLUMN PER PLAN T.O.S COL. WHERE OCCURS
