Two adjacent concrete tilt-up wall panels rest on a continuous concrete footing. Tilt-up panel grout fills the vertical joint between the panels. Footing reinforcement includes Z-bars and transverse reinforcing bars matching the continuous footing reinforcement schedule. Panels are positioned over the footing with a specified lap length for the reinforcement. The assembly references a typical connection at the footing base.
