This structural detail shows a column section on a centerline with a detail reference marker pointing to sheet S5.20. Dashed lines indicate hidden structural elements or clearances around the column profile. Centerline grids cross through the primary framing member.
Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
Start membership
