This connection features a C-beam joined to a steel plate measuring three and one-half inches by five-sixteenths of an inch. The assembly utilizes five-sixteenths inch fillet welds to secure the channel web to the plate. The plate is positioned with a six-inch vertical dimension, featuring a three-inch spacing between bolt hole centerlines and one and one-half inch edge distances. The connection is centered horizontally with a four-inch total width and a two-inch offset from the channel flange.
