A structural steel beam connects to a column using top and bottom plates welded to the column flanges with five-sixteenth inch fillet welds. Plates are one-half inch thick for five or fewer bolts, and five-eighths inch thick for more than five bolts. Shear plates and bolts are sized per plan. AISC K1 dimensions apply to the column web.
1" 1 3/4" 1 3/4" C L COL PL 1/2" T&B FOR (5) AND FEWER BOLTS, PL 5/8" T&B FOR MORE THAN (5) BOLTS BEAM PER PLAN FOR SHEAR PL AND BOLTS, SEE 'A' SEE SCHED COLUMN PER PLAN 5/16 PL TO COL FLGS TYP AISC K1 PER 3 S8.10
