A concrete slab-on-grade rests on a minimum six-inch aggregate base over a minimum twelve-inch layer of non-expansive soils or structural fill per the geotechnical report. A vapor retarder is installed directly beneath the concrete slab. Grade 60 reinforcing steel is placed at mid-depth, consisting of number five bars at twelve inches on center each way, with an alternate spacing of number five bars at sixteen inches on center each way. Reinforcing must be properly secured to remain at mid-depth during slab placement, and the slab installation must follow the completion of underground utilities.
CONCRETE SLAB-ON-GRADE REINFORCEMENT - SEE SCHEDULE BELOW FOR DEPTH LOCATION, SIZE, & SPACING VAPOR RETARDER - SEE STRUCTURAL SPECIFICATIONS 12" MIN. NON-EXPANSIVE SOILS OR STRUCTURAL FILL - SEE GEOTECHNICAL REPORT SLAB THICKNESS REINFORCING 8" #5 @ 12" O.C. EA. WAY AT MID-DEPTH 1 Gr. 60 ALTERNATE #5 @ 16" O.C. EA. WAY AT MID-DEPTH SLAB THICKNESS - SEE PLAN 6" MIN. AGGREGATE - SEE GEOTECHNICAL REPORT NOTE: 1. PROPERLY SECURE REINFORCING TO REMAIN AT MID-DEPTH DURING SLAB PLACEMENT 2. DO NOT INSTALL SLAB PRIOR TO COMPLETION OF UNDERGROUND UTILITIES.
