A structural steel channel connects adjacent to a roof deck opening using an L8x4x1/2 angle welded to the top flange and channel web. A five-sixteenths inch fillet weld secures the angle to the top flange, while a three-sixteenths inch fillet weld connects the channel web to the angle. The deck opening maintains a zero-inch minimum to three-inch maximum typical clearance. A one-inch maximum dimension governs the offset at the support beam.
L8x4x1/2x0-6" LLV DECK ATTACHMENT TO SUPPORT - SEE DECK ATTACHMENT DIAGRAM NOTES: 1. SEE FOR S.O.M.D. OPENING. SEE & FOR ROOF DECK OPENING. 1" MAX. DECK OPENING 0" MIN. 3" MAX. CLR., TYP. 5/16 TYP. @ ANGLE TO TOP FLANGE 5/16 5/16 TYP. @ CHANNEL WEB TO ANGLE 3/16 3/16 TYP. @ CHANNEL WEB TO ANGLE
