Structural · S-8HQTF

Concrete Shear Wall Cross Tie and Plate Assembly

Elements

About this detail

A thirty-six-inch thick concrete shear wall assembly incorporates typical cross tie rods spaced at thirty-six inches. Plate thickness is sized per the concrete shear wall elevations. The assembly includes a specific dimensional allowance to accommodate protruding cross ties, applied fireproofing, and architectural facing materials on the exterior boundary.
