An L-shaped anchor bolt is embedded in a concrete element with a minimum two-inch embedment unless otherwise noted, measured from the face of the concrete to the hook. A bolt embedment schedule matches bolt sizes ranging from one-half inch to one inch with required embedment depths of five inches up to seven inches. General notes specify a minimum bolt spacing of twelve bolt diameters and a minimum edge distance of six diameters.
BOLT EMBEDMENT SCHEDULE 1/2" 3/4" 5/8" 7/8" BOLT SIZE 1" 7" 5" 6" 5" 5" EMBEDMENT FACE OF CONC NOTE: MINIMUM BOLT SPACING SHALL BE 12 BOLT DIAMETERS WITH A MINIMUM EDGE DISTANCE OF 6 DIAMETERS. SEE SCHEDULE MIN EMBEDMENT UNO 2" MIN
