S-8GMD6 — Provide 2Mm Shims Under

Structural · S-8GMD6

Provide 2Mm Shims Under

Units: metric
Sheet: S-MB-5.05
Discipline: Structural

Materials

Metal (misc.)Steel

Elements

Connections / Plates Roof / Floor Openings

Connections

HSS Connection Welded Connection

Text on the drawing

PIT OPENING 1040 CLR 1070 PIT OPENING 660 560 50 HSS64x64x6.4 HSS64x64x6.4 HSS64x64x6.4 PROVIDE 2MM SHIMS UNDER HSS, WELDED GALVANIZED TOGETHER WITH HSS FRAMES, TYP 6 LOCATIONS 4 S-MB-5.05

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
