S-8FZVX — Lateral Bracing To Beam And Roof Connection

Structural · S-8FZVX

Lateral Bracing To Beam And Roof Connection

Units: metric
Sheet: S-OB-5.52
Discipline: Structural

Materials

Steel Timber / Wood

Elements

Beams Bracing Columns Connections / Plates Roofs

Connections

Beam-to-Column Bolted Connection Bracing Connection Gusset Plate HSS Connection Timber / Mass-Timber Connection

Text on the drawing

200 GLULAM BEAM HSS COLUMN HSS BRACE PL6 BOTH FACES STIFF PL12 THROUGH BOLTS, SEE PLAN AND SCHEDULE FOR CONNECTION LOADS GUSSET PL12 MIN BEARING PL16 U/S OF OB ROOF 117.77 6 6
