A structural steel framing connection occurs at a steel column supporting a steel joist and steel beam. A tie plate measuring 3/8" x 4" x 2'-0" slots through the steel column, with 3/16" welds securing the plate to the joist and beam. The 7-1/2" deep girder bearing end connects to the column using two 3/4" diameter A325 erection bolts. The 5" deep joist bearing end similarly utilizes two 3/4" diameter A325 erection bolts and features an L5x5x3/8 angle spanning the column width with a 3/8" stiffener plate. Stabilizer plates are provided at girders and joists, including a 3/4" x 6" x 0'-6" plate at girders and a 3/8" x 6" x 0'-6" plate with a 13/16" diameter hole at joists. Bottom chords are left un-welded to the stabilizer plate unless noted otherwise.
NOTE: DO NOT WELD BOTT CHORDS TO STABILIZER PL (UNO) STABILIZER PL: 3/4"x6"x0'-6", TYP AT GIRDERS L5x5x3/8 x COL WIDTH W/ 3/8" STIFF PL PL 3/4"x6" x GIRDER WIDTH + 1" W/ PL 1/2"x15" SLOTTED THRU COL STABILIZER PL: 3/8"x6"x0'-6" W/ 13/16"Ø HOLE TYP AT JST 5" DEEP JST BRG END W/ (2) 3/4"Ø A325 ERECTION BOLTS 7 1/2" DEEP GIRDER BRG END W/ (2) 3/4"Ø A325 ERECTION BOLTS TYP 1/4 2 TYP 3/16 3/16 TYP 5/16 5/16 STL COL STL JST, STL BM AT SIM COND TIE PL 3/8" x 4" x 2'-0" SLOT PL THRU COL 3/16 PL TO JST/BM 3/16 COL ABV WHERE OCCURS
