A light gauge steel joist bears near the top of a non-bearing steel stud shear wall. Three number twelve self-drilling Tek screws connect each stud to the joist framing. Roof sheathing ties into the assembly at the top flange. Shear wall sheathing and exterior finishes are coordinated per architectural drawings.
STL STUD WALL, SEE SCHED ROOF SHTG FINISH SURFACE, SEE ARCH LIGHT ga STEEL JST (3) #12 TEK SCREWS AT EA STUD SW SHTG EXT FINISH, SEE ARCH
