Structural · S-8DNA9

HSS Column to Beam Top Connection

Materials

Steel

Elements

Beams Connections / Plates

Connections

HSS Connection Bolted Connection

About this detail

A structural steel beam connects to the top of a hollow structural section column with a three-quarter-inch-diameter erection bolt and five-sixteenth-inch fillet welds. A one-quarter-inch stiffener plate measuring one-half the beam depth minimum is provided on each side where no intersecting beam occurs, welded with one-quarter-inch fillet welds. A shear plate extends for intersecting beams to the bottom flange on each side, with a maximum one-half-inch gap maintained at the column top. The plate measures three-eighths of an inch thick by the hollow structural section width plus one inch wide, centered on each side of the hollow structural section.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
