A structural steel beam per plan connects to a hollow structural section column using a typical quarter-inch by four-inch by zero-foot-six-inch steel side plate welded with a quarter-inch fillet weld four inches minimum typical. The connection utilizes two three-quarter-inch diameter through bolts placed in horizontal short slotted holes with typical side plates on each side.
SIDE PLATE, TYP THRU BOLTS, TYP SECTION SECTION 1/4 4 MIN TYP BEAM PER PLAN, TYP PL1/4x4x0'-6" W/ (2) 3/4"Ø THRU BOLTS IN HORIZ SHORT SLOTTED HOLES 1" 1 1/2" 3"
