The plan view shows an L 3x3x1/4 angle and 16-gauge filler plate typically connected with a 1/4-inch bent plate, alongside an L 3x3x1/4 angle per metal deck support at the column detail, framing into a wide flange or box column with a maximum 3-inch clearance. The section view details 3/4-inch diameter by 6-inch studs spaced at 9 inches at the column only with two per column minimum, supporting a topping slab over metal deck connected to a steel beam. Fillet welds of 3/16-inch size secure the connection assemblies to the column. Notes indicate that this detail is similar at exterior corner conditions and at opposite column orientation.
