A wide flange beam connects to the web of a wide flange column where the beam fits inside the column depth. A shear plate is welded to the column web and bolted to the beam web using a typical shear plate connection detail. The assembly is sized per plan with top of steel elevations referenced accordingly.
BEAM PER PLAN, TYP BEAM TO WIDE FLANGE COLUMN FLANGE SHEAR PLATE INFORMATION PER TYPICAL SHEAR PLATE CONNECTION. COL PER PLAN TYP SHEAR PL CONN BEAM PER PLAN, TYP CL COL BEAM TO WIDE FLANGE COLUMN WEB - OPTION 1 (BEAM FITS INSIDE COLUMN) SHEAR PLATE INFORMATION PER TYPICAL SHEAR PLATE CONNECTION. BEAM WHERE OCCURS PER PLAN T/STL PER PLAN
