A two-inch ASTM A572 Grade 50 embed plate features standard holes and coordinates with a matched base plate. Anchor bolts are arranged in two rows across the rectangular steel plate assembly. General notes indicate the extent of the protected zone and reference sheet S6.10 for the gusset plate connection.
3" 3" BASE PL MATCH BASE PL MATCH PLAN AT EMBED PLATE ELEVATION AT FOUNDATION NOTES: 1. INDICATES EXTENT OF PROTECTED ZONE. 2. FOR GUSSET PLATE CONNECTION, SEE SHT S6.10. 2" EMBED PLATE A572 GR50 W/ STD HOLES CLR
