A joist girder bears on a structural column connection utilizing a one and one-quarter inch seat plate with unslotted bolt holes. A stabilizer plate is welded to the assembly with a five-sixteenths fillet weld applied on three sides. The vertical depth varies as detailed on the plan.
STABILIZER PLATE, SEE . NO SLOT AT HOLES JOIST GIRDER 9 B4-S3.0 VARIES - SEE PLAN ~ 1 1/4" SEAT PL. 3 SIDES 5/16
