An intersecting steel beam connects to a supporting beam using a WT section per plan with a three-eighths-inch shear plate shaped to fit around the flange. For conditions where the intersecting beam depth is greater than ten inches, full-height three-eighths-inch stiffener plates are installed on both sides with five-sixteenths-inch fillet welds. For conditions where the beam depth is less than ten inches, similar stiffening and three-eighths-inch shear plates with specified bolts and welds are applied. Additional information is referenced to sheet 2-S6.13.
CONDITION WHERE INTERSECTING BEAM "d" < 10" WT PER PLAN BEAM PER PLAN NOTE: FOR REMAINDER OF INFO. SEE BOTH SIDES WHERE OCCURS BEAM PER PLAN SHEAR PLATE, BOLTS, and WELD PER SIM. FULL HT. STIFF PLATE 3/8" - BOTH SIDES _ FULL HT. STIFF PLATE 3/8 CONDITION WHERE INTERSECTING BEAM "d" > 10" WT PER PLAN BEAM PER PLAN BOTH SIDES WHERE OCCURS BEAM PER PLAN BOLTS PER SIM. SHEAR PLATE 3/8" - SHAPE TO FIT AROUND FLANGE FULL HT. STIFF PLATE 3/8 "d" 5/16 5/16 AWS MIN. "d" 11 2-S6.13 01 2-S6.11 01 2-S6.11 A B
