Metal panel installation conditions over parallel and perpendicular beam supports feature a thirty-six-inch wide panel module. Edge and intermediate support conditions incorporate five-eighths-inch diameter fasteners spaced at six inches on center maximum alongside top seam welds. Optional metal closure strips and specific weld patterns to the support are provided where required. A minimum two-inch bearing is maintained at support locations typical unless otherwise noted.
BEAM SUPPORTS, TYP TOP SEAM WELD @ 6" OC MAX WELD PATTERN BELOW METAL CLOSURE STRIP IF REQ'D METAL CLOSURE STRIP IF REQ'D WELD PATTERN TO SUPPORT UNO BRG TYP 2" MIN 36" WIDE PANEL 5/8"Ø 5/8"Ø 6" OC EDGE INTERMEDIATE PARALLEL SUPPORTS SIDE SEAM JOINT INTERMEDIATE EDGE PERPENDICULAR SUPPORTS
