A wide-flange steel beam is reinforced with top and bottom plates welded to the flanges where indicated. Top plates are joined to the top flange with typical fillet welds, while bottom plates are secured to the bottom flange with corresponding fillet welds. Dimension lines denote the width of the plates and the beam profile geometry.
TOP PL, ES, WHERE INDICATED TYP Wt Wb Wb BOT PL 1 3/4" 12" 5" WIDTH WIDTH k TOP PL, ES, WHERE INDICATED TYP Wt Wb Wb BOT PL 1 3/4" 12" 5" WIDTH WIDTH k
