A glulam column bears on a three-quarter-inch steel base plate with one-half-inch chamfered corners, dapped into the bottom of the column. A central pipe and two one-half-inch diameter by four-and-three-quarter-inch steel pins provide connection support. The pins are countersunk, centered, and plugged with wood dowels. A typical one-eighth-inch gap is maintained on all sides.
SECTION A-A SECTION B-B 3/4" BASE PL w/ 1/2" CHAMFER AT CORNERS DAPPED INTO BOT. OF COL. PIPE (2) 1/2"Ø x 4 3/4" STEEL PINS COUNTERSINK TO BE CENTERED AND PLUG w/ WOOD DOWELS GLULAM COLUMN TYP. 2" ALL SIDES 1/8" GAP TYP. TYP. 2" TYP. 2" TYP. 4" 6
