A vertical and horizontal screen wall support connection utilizes hollow structural section (HSS) posts and flat members as indicated on plan and elevation. The framing incorporates top and bottom L4x4x3/8 structural angles connected with one-quarter-inch fillet welds and three-inch returns typically. Bearing plate information is referenced to detail one on sheet SH8.1.
HSS(FLAT) PER ELEV HSS(FLAT) PER ELEV HSS POST PER PLAN / ELEV VERTICAL AND HORIZONTAL SCREEN WALL SUPPORT CONNECTION A L4x4x3/8(T&B) TYP 1/2" 1/4 1/4 +3" RET TYP +3" RET TYP FOR BEARING PLATE INFO, SEE 1 SH8.1
