Roof to Floor Deck Transition - No Brick

Materials

Concrete Steel Timber / Wood Brick Metal (misc.)

Elements

Beams Walls Facades / Cladding Roofs Ceilings Floors / Slabs Decks Arches Bracing Connections / Plates

Connections

HSS Connection Bracing Connection

About this detail

Roof-to-floor deck transition at an open web steel joist bearing without brick veneer, featuring a concrete slab over metal deck supported by structural steel beams and joists. An edge angle is provided at the perimeter of the concrete slab, and a continuous L3x3x1/4 angle serves as deck support. Hollow structural section blocking is installed with a height matching the joist seat depth, a minimum one-quarter-inch wall thickness, and a minimum two-and-a-half-inch width, connected per structural plans. A one-inch bearing shim is included as required for joist bearing. Steel stud walls feature deflection tracks where applicable, and wall finishes, roofing, soffits, and ceilings are coordinated per architectural drawings.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
