This assembly features a continuous L6x4x5/16 steel angle ledger anchored to a concrete wall with 3/4-inch diameter stud anchors spaced at 16 inches on center, starting 8 inches from the end. A single continuous number 5 reinforcing bar is embedded within the concrete wall. Timber framing members, specifically 4x6 Douglas Fir, are supported by Simpson Strong-Tie F-hangers spaced at 4 feet on center. The connection utilizes L 2 1/2x2x1/4 steel angles on each side of the timber members, secured with two 7/8-inch diameter through-bolts. A strap and pins are installed per the project nailing note with 4-inch spacing.
Text on the drawing
L2 1/2x2x1/4 (ES) (LLV) @ EA 4x 4x6 #2 D.F. IN SIMPSON F HANGER @ 4'-0"OC L6x4x5/16 CONT LEDGER W/ 3/4Ø STUD ANCHORS @ 16"OC (START BOLTS 8" FROM END) (1) #5 CONT 2" 8" 6" (2) 7/8"Ø THRU BOLT 2" 2" 1/4 INSIDE EA LEG TYPICAL 4" STRAP AND PINS PER NAILING NOTE "4" AT BN SPACING
