A structural steel column bears on a steel base plate anchored to a concrete footing. A one and one-half inch layer of non-shrink grout fills the space beneath the base plate. The surrounding concrete slab on grade includes a concrete blockout detailed per typical details. A plumbing line passes through the assembly with a twenty-four inch minimum clearance coordinated per plan.
CONCRETE BLOCKOUT, SEE TYPICAL DETAILS STEEL BASE PLATE STEEL COLUMN 1 1/2"NON-SHRINK GROUT CONC. FOOTING CONC SLAB ON GRADE, SEE PLAN NOTE: FOR STEEL COLUMN AT PIPE/DOWNSPOUT SEE 13/S501 24" MINIMUM, COORDINATE w/ PLUMBING SEE PLAN 5/16 SEE PLUMBING FOR LOCATION, SIZE AND DIRECTION STEEL BASE PLATE CONCRETE BLOCKOUT, SEE TYPICAL DETAILS CONC. FOOTING STEEL COLUMN 1 1/2" NON-SHRINK GROUT CONCRETE SLAB ON GRADE
