Continuous wood blocking built up solid to the top of insulation bears on a metal roof deck supported by an L6x4x3/8 deck support angle. The assembly is secured using one-half-inch diameter threaded studs or through-bolts with recessed watertight nuts spaced at twenty-four inches on center maximum and twelve inches maximum from ends and splices. Additional ripped blocking is provided at deck support points to prevent deck crushing as required.
C SECTION CONT WOOD BLOCKING BUILT UP SOLID TO TOP OF INSULATION 1/2" DIA x THREADED STUD OR THRU BOLTS WITH RECESSED WATER TIGHT NUT AT 24" OC MAX AND 12" MAX FROM ENDS/SPLICES. ROOF ASSEMBLY REF ARCH CONT WOOD BLOCKING BUILT UP SOLID TO TOP OF INSULATION 1/2" DIA x THREADED STUD OR THRU BOLTS WITH RECESSED WATER TIGHT NUT AT 24" OC MAX AND 12" MAX FROM ENDS/SPLICES. ROOF ASSEMBLY REF ARCH PROVIDE ADDITIONAL RIPPED BLOCKING AT DECK SUPPORT POINTS TO PREVENT DECK CRUSHING AS REQUIRED L6X4X3/8 (LLV) DECK SUPPORT ANGLE (TYP) METAL ROOF DECK REF PLAN METAL ROOF DECK REF PLAN
