A louver support post connects to the mullion with a notched splice joint. Typical brackets secure the assembly using five-eighths-inch diameter ASTM A307 machine bolts spaced at eight inches on center with one-and-a-half-inch typical edge distances.
TYPICAL BRACKET 8" TYP. 1 1/2" EDGE OF LOUVER NOTCH AND SPLICE MULLION AT LOUVER SUPPORT POST 5/8"Ø 'A307' M.B., TYP PLAN VIEW 8"
