S-7S644 — Typical Bulkhead Plate Mounting with Tinned Copper Angle

Structural · S-7S644

Typical Bulkhead Plate Mounting with Tinned Copper Angle

Materials

Steel Stainless Steel Metal (misc.)

Elements

Ceilings Connections / Plates

Connections

Bolted Connection

About this detail

A stainless steel back panel is mounted using one-inch 600-volt insulated standoffs to maintain separation. A four-inch by four-inch by one-quarter-inch tinned copper angle connects to the assembly using typical bolts with washers.

TYPICAL BULKHEAD PLATE MOUNTING STAINLESS STEEL BACK PANEL 1" 600V INSULATED STANDOFF 4" X 4" X 1/4" TINNED COPPER ANGLE BOLT W/ WASHER, TYP
