A mass timber lower column splice and cross-laminated timber panel joint centers on grid. The assembly features a panel-to-panel spline connection secured with thirteen SDCP27614 structural screws spaced in six equal increments. Alignment and load transfer are maintained using three-quarter-inch by four-inch smooth dowels installed in seven-eighth-inch predrilled holes. Dimensions and fastener layouts are specified for typical installation.
TYP. 8" MAX. CLT PANEL JOINT CENTERED ON GRID PANEL-PANEL SPLINE CONNECTION REF. PANEL LAYOUT PLAN 3/4"x4" SMOOTH DOWEL IN 7/8" HOLE TYP. 1/2" 1/2" 1 3/4" 1 3/4" 1 3/4" 1 3/4" (13) SDCP27614 FOR SCREW LAYOUT (6) EQ. SPACES LOWER COL. SPLICE SCREW LAYOUT
