A reinforced concrete column section features six number nine vertical bars arranged in a two-by-three total configuration extended from the story below. Number four ties and hairpins spaced at six inches on center typical enclose the vertical reinforcement. The assembly maintains a three-quarter inch clear cover typical, with a cast downface indicated on the outside face. Additional dimensional constraints include an eight inch maximum spacing typical and a five and one-quarter inch dimension.
