Reinforcing bars extend from the tie beam into the pile cap for required development length, aligning with the top of the pile cap. The column base plate sits on the structural foundation with anchor bolts extending into the concrete element. Proper alignment is maintained between the tie beam top and the top of the pile cap.
CL EXTEND BARS INTO PILE CAP FOR DEVELOPMENT LENGTH ALIGN WITH TOP OF PILE CAP 17
