Hollow structural section eight by six by three-eighths guide rail support extensions attach to a hollow structural section column sized per plan. A quarter-inch fillet weld secures the extension to the column. The maximum extension length is eight inches.
8" MAX. 1/4 HSS 8 x 6 x 3/8 GUIDE RAIL SUPPORT EXTENSIONS (WHERE OCCURS) COORDINATE W/ ELEVATOR MANUFACTURER HSS COLUMN - SEE PLAN
