Provide one row of 150U050-54 bridging at the mid-span of ceiling joists or at eight feet zero inches on center maximum. Fasten a Simpson SUBH clip to each joist using one number ten self-tapping metal screw connected to the cold-rolled channel at each clip. At the rim track, attach the end of the cold-rolled channel to the rim track using a 54 mil by four-inch clip with two number ten self-tapping metal screws to the channel and two number ten self-tapping metal screws to the rim.
PROVIDE (1) ROW OF 150U050-54 @ MID- SPAN OF CEILING JOISTS OR 8' - 0" OC MAX W/ SIMPSON SUBH @ EA JOIST W/ (1) #10 SMS TO COLD-ROLLED CHANNEL @ EA CLIP. @ RIM TRACK, ATTACH END OF COLD- ROLLED CHANNEL TO RIM TRACK W/ 54 MIL x 4" CLIP W/ (2) #10 SMS TO CHANNEL & (2) #10 SMS TO RIM 1 1/2" TYP 4" TYP
