This roof edge assembly details the structural steel beam framing supported by hollow structural section columns at the building perimeter. Exterior sheathing and wall veneer are coordinated with the architectural drawings and mounted against the steel framing elements. Detail callouts reference adjacent connections for the roof deck, window head, and support brackets.
190381_S523-03 3 EDGE DETAIL AT ROOF SEE ARCH 7 S521 12C S511 12A S511 11 S511 10 S511 EXTERIOR SHEATHING, SEE ARCH VENEER, SEE ARCH BETWEEN HSS SUPPORT T.O. WINDOW
