Concrete slab-on-grade depressions accommodate shallow drops of two inches or less and deeper recesses up to one foot six inches. The assembly incorporates typical slab reinforcement paired with continuous number four nosing bars placed at the depression transitions. Dimensions establish clear clearances, transition slopes, and edge distances per plan requirements.
2' - 0" SEE PLAN 2" MAX. SLAB DEPRESSION - 2" OR LESS 1' - 6" MAX. SEE PLAN SLAB DEPRESSION - GREATER THAN 2" CLR. NOTES: 1. FOR ADD'L INFO., SEE . TYP. SLAB REINF. 6" 3 / - 1" 2' - 0" 2' - 0" 6" #4 CONT. NOSING BAR AND AT DEPRESSION #4 CONT. NOSING BAR AND AT DEPRESSION
