A beam web connects to a structural column flange using a Grade 50 steel plate with a thickness designated as Tp, welded to the support and bolted to the supported member. High-strength bolts are spaced at three inches on center, maintaining minimum edge distances on the connection plate. Skewed conditions are detailed per project notes, sizing members as indicated on plan.
COLUMN, SEE PLAN BEAM, SEE PLAN TYP 1 1/2" NR BOLTS @ 3" OC Ed MIN NC BOLTS AT 3" OC Ed MIN "Tp" THICK GR 50 (FY =50 KSI) PLATE (E) (E) SEE NOTES FOR SKEW
