The Pro-XTC header connects to the jamb stud using a six-inch Pro-X clip with sheet metal screws, or self-tapping screws when framing into hollow structural section jambs. Infill studs match the typical wall stud size and type specified on the plans. The header member is sized per the elevation drawings and attaches through the clip assembly.
1-12 TYP BOX STUD CONN JAMB PER ELEVATION (HSS WHERE OCCURS) INFILL STUD MATCH TYP. WALL STUD PER WALL TYPE HEADER PER ELEVATION 6" PRO-X CLIP - 54 W/ SMS SCREWS PER SECTION A-A (USE SELF-TAPPING SCREWS AT HSS JAMBS) PRO-XTC HEADER E HEADER TO JAMB CONNECTION (PRO-XTC HEADER: ICC #IAPMO-ER 0286) A A
