A structural steel column rests on a steel base plate with a thickness of one and one-half inches, bearing over a layer of non-shrink grout. Anchor bolts extend through oversized holes in the base plate and are secured with heavy-duty washers with standard-sized holes. The contractor must provide and coordinate the means for leveling and elevation control.
MILL MEANS OF LEVELING & ELEVATION CONTROL SHALL BE PROVIDED & COORDINATED BY THE CONTRACTOR HEAVY DUTY WASHER w/ STANDARD SIZED HOLE - TYPICAL REFER TO BASE PLATE SCHEDULE FOR ANCHOR BOLTS & BASE PLATE COLUMN BEARING EL- REFER TO SECTIONS NON-SHRINK GROUT PROVIDE OVERSIZED HOLE IN BASEPLATE BASE PL. THICKNESS (t) 1-1/2"
