An epoxy-coated soldier beam extends downward into the subgrade to support an existing slope with a finished shotcrete face. The embedment depth "D" and exposed height "H" are sized per the soldier beam schedule. A typical freeboard detail is located at the top of the shoring wall adjacent to the existing slope.
FINISHED SURFACE SHOTCRETE FACE (SEE DETAIL 2/SH7) EPOXY COATED SOLDIER BEAM (SEE SCHEDULE & DETAIL 1/SH7) NOTES: 1. FIELD VERIFY ALL EXISTING & PROPOSED STRUCTURES PRIOR TO SHORING INSTALLATION. 2. SEE SOLDIER BEAM SCHEDULE ON SHEET SH8 FOR "H" & "D". FREEBOARD, TYP. (SEE DETAIL 3/SH7) "H" "D" (E) SLOPE 480.00' 490.00' 500.00' 510.00' 480.00' 490.00' 500.00' 510.00'
