A wide-flange beam connects to a hollow structural section column web using a welded shear tab plate and multiple rows of bolts. The shear tab sizing, edge distances, and bolt spacings comply with AISC specifications and the project schedule. A full-height shear tab is omitted for W12 beams and smaller per engineering notes. Fillet welds are specified typically at five-sixteenths inches, and dimensional clearances maintain the required k-distance per the AISC manual.
NOTE: SHEAR TAB - SEE SCHEDULE (FOR EDGE DISTANCE AND BOLT SPACING SEE AISC SPECIF,TYP) SEE "NON-MOMENT CONN NOTE" NO. 4 "K" PER AISC MANUAL FULL HEIGHT SHEAR TAB NOT REQUIRED AT W12 BEAMS & SMALLER . 2ND ROW OF BOLTS WHERE OCCURS 5/16 TYP S6-121 11 NOTE: SEE 4/S5-101 FOR MORE INFORMATION S.A.D C:\Revit Local Files\19001941- 2111 University Plaza Phase 2_R20_eagnes.rvt
