S-7AC69 — Cold-Formed Steel Sil Track Anchorage

Structural · S-7AC69

Cold-Formed Steel Sil Track Anchorage

Scale: 1" = 1'-0"
Units: imperial
Sheet: S7.01
Discipline: Structural

Materials

Cold-formed Steel Steel Timber / Wood

Elements

Anchors / Embeds Beams Expansion / Control Joints Roof / Floor Openings Walls Windows

Connections

Base Plate / Anchorage Bolted Connection

Text on the drawing

14 COLD-FORMED STEEL FRAMED WINDOW OPENING 1" = 1'-0" REF. 10/S7.01 FOR LOOSE LINTELS AT HEADERS. CONT. 600T125-43 BASE TRACK STUD, REF. PLAN 0.157" -DIA LVF @ 16" o.c. 2" MAX. 3" MIN. EDGE CLEARANCE
