Metal deck opening closure assembly supported by an angle frame and reinforcing bars at a bare steel deck. Eighteen-gauge closure profiles are provided parallel and perpendicular to the deck span, with horizontal legs extended to tack weld and bear on 2-1/2 by 2-1/2 by 3/16 inch angles. The support angles extend beyond the opening at each end over three full uncut low flutes typically with a maximum span of two feet. Adjacent beams require closures or two number 4 bars in each low flute per the specified details.
CLOSURE ALL SIDES OF OPENING - EXTEND HORIZONTAL LEG OF CLOSURES PARALLEL TO DECK SPAN TO TACK WELD and BEAR ON L2-1/2x's BEYOND L2-1/2x2-1/2x3/16 - EXTEND BEYOND OPENING EACH END OVER 3 FULL (UNCUT) LOW FLUTES TYP. 2'-0" MAX. NOTE: WHERE BEAMS OCCUR ADJACENT TO SIDES OF OPENING, PROVIDE CLOSURE PER OR (2) #4 EACH LOW FLUTE CLOSURE PROFILE PERPENDICULAR TO DECK SPAN 2 1/8 CLOSURE PROFILE PARALLEL TO DECK SPAN 2" 2" 18 GA. 18 GA. 18 GA. 1/2" 1/2" SECTION AT BARE DECK (NO CONCRETE FILL) NOTE: FOR REMAINDER OF INFO SEE SECTION AT CONCRETE FILLED DECK BELOW 1 S0.23 2 S0.23
