A full-height shear plate connects to each side of the beam web per the typical beam connection detail. The beams frame into a column centered on the column line, with a transverse beam centered on the column per plan. Connection bolts secure the top and bottom framing flanges relative to the column centerline.
CL COL FULL-HEIGHT SHEAR PLATE EACH SIDE OF BEAM WEB PER TYPICAL BEAM CONN DETAIL BEAM PER PLAN TRANSVERSE BEAM CENTERED ON COLUMN PER PLAN (NOT SHOWN FOR CLARITY) A A A A
