An angle kicker is anchored to the underside of a metal deck with two quarter-inch diameter concrete screw anchors providing a nominal embedment of one and five-eighths inches. The screws are centered within the metal deck valley. The angle member measures six by two inches by fourteen gauge and is one foot four inches long.
L6x2x14 GA x 1'-4 WITH (2) 1/4"Ø CONCRETE SCREW ANCHORS w/ 1 5/8" NOMINAL EMBED. CENTER SCREWS IN METAL DECK VALLEY WP WP L6x2x14 GA x 1'-4 WITH (2) 1/4"Ø CONCRETE SCREW ANCHORS w/ 1 5/8" NOMINAL EMBED METAL DECK EQ EQ EQ EQ KICKER KICKER EQ EQ OPTION A
